Introduction
The center-axle timber flatbed trailer is a flatbed trailer with its axle positioned at the center of gravity. It features a flat cargo platform made of high-strength steel, suitable for transporting long-length goods such as timber.
Core Advantages
Adaptation to Timber Transportation Scenarios: The center-axle design lowers the center of gravity; combined with the flat cargo platform, it ensures stable driving and low risk of rollover, easily handling complex road conditions such as mountain roads.
Strong Load Capacity and Secure Fixation: Load capacity reaches 10-24 tons depending on the number of axles. Equipped with dedicated binding devices, it can firmly secure long-length timber.
Efficient Transportation: Supports drop-and-hook transportation, significantly improving transport efficiency.
Product Parameters
|
Category |
Specific Parameters |
|
Overall Dimensions |
Length ≤ 12m (compliant upper limit), Width ≤ 2.55m, Height ≤ 4m; Cargo platform length: 8-13m, suitable for long-length timber. |
|
Axle Group & Load Capacity |
Number of axles: 1-3 (3 axles as mainstream); Load limits: 10 tons for 1 axle, 18 tons for 2 axles, 24 tons for 3 axles (compliant upper limit); custom models can reach 40-80 tons. |
|
Core Structure |
Frame material: Q345B/ST52-3 high-strength steel; main beam height: approx. 500mm; Cargo platform: flat checker plate, equipped with 12-30 binding hooks/twist locks. |
|
Key Systems |
Braking: dual-line air brake (brands such as WABCO) with ABS; Suspension: mechanical leaf spring or air suspension; Electrical: 24V voltage, LED lights. |
|
Traction & Support |
Tow pin specification: 2" or 3.5"; vertical static load ≤ 10% of the trailer's maximum mass or 10000N; Support legs: 28-ton class (brands such as JOST). |
FAQ
Q: What procedures are required for export, and can assistance be provided?
A: Export license, certificate of origin, and test report are required. We can assist in organizing customs declaration documents and handling certification on behalf to simplify the process.
Q: Is overseas after-sales service and spare parts supply convenient?
A: Technical support is provided through cooperative networks; flatbed reinforcement parts and axle components can be quickly supplied through overseas warehouses.
Q: What should be noted when packing for transportation?
A: Fix flatbed anti-slip parts to prevent collision, protect axle group connectors, and verify documents and vehicle information before shipment to avoid customs clearance delays.
