Introduction
The four-axle side-tip dump semi-trailer adopts a four-axle load-bearing design to enhance load capacity and stability. It relies on a side-tip hydraulic device to achieve efficient unloading and is suitable for transporting various types of heavy bulk cargo.
Core Advantages
Strong Load-Bearing + High Stability: The four-axle design distributes weight, with a rated load capacity of up to 40-90 tons, which meets heavy-load requirements. It has stronger grip during driving and reduces the risk of rollover.
Efficient and Convenient Unloading: The hydraulic side-tip system can complete unloading quickly without relying on external equipment. The single unloading time only takes 1-3 minutes, greatly improving operation efficiency.
High Durability: The cargo box is mostly made of high-strength wear-resistant steel, which can withstand impacts from heavy objects such as sand and ore. It is suitable for harsh working conditions and reduces maintenance costs.
Main Application Fields: Mainly used in mine mining, infrastructure projects and building materials transportation.
Specifications
|
Category |
Specific Specifications |
|
Basic Information |
Vehicle Type: Four-Axle Side-Tip Dump Semi-TrailerCurb Weight: 8.5-14.3 Tons |
|
Dimension Parameters |
Inner Length of Cargo Box: 12.8-16 MetersInner Width of Cargo Box: 2.3-2.6 MetersStake Height: 0.6-2 MetersOverall Vehicle Dimensions: 13 × 2.4-2.69 × 3.5-4 Meters |
|
Load-Bearing Parameters |
Rated Load Capacity: 40-90 TonsAxle Configuration: 4 Axles × 13-16 TonsTire Specification: 12R22.5/12.00R20 |
|
Performance Parameters |
Lifting System: HYVA/BINOTTO Hydraulic Side-Tip SystemCargo Box Material: Q345B / High-Strength Wear-Resistant SteelBrake System: Dual-Circuit Pneumatic Brake + WABCO ValveSuspension Type: Mechanical Suspension / Air Suspension |
