Introduction
The 12m three-axle stake semi-trailer features a 12-meter load-bearing length, a three-axle support design, and a stake protective structure. It is suitable for various freight scenarios.
Core Advantages
Compliance & Universality: The 12-meter length and three-axle layout comply with weight limits in multiple regions and meet access standards of multiple countries.
Efficient Load-Bearing: It has a rated load capacity of 30-65 tons, and the open stakes enable flexible loading and unloading.
Adaptation Dividend: It aligns with the infrastructure needs of the "Belt and Road Initiative", with a mature supply chain, fast delivery, and low operating costs.
Wide Applications
Infrastructure Construction: Transports steel bars, cement and other construction materials, and copes with complex road conditions.
Logistics: Carries home appliances and agricultural products, and is suitable for cross-border/long-distance transportation.
Resource/Industrial Sectors: Transports minerals and small-to-medium-sized equipment, and resists heavy loads and impacts.
Specifications
|
Parameter |
Details |
|
Length (mm) |
12000 |
|
Width (mm) |
2550 |
|
Stake Height (mm) |
600-1800 |
|
Axle Configuration |
Three Axles |
|
Rated Load Capacity |
30-65T |
|
Tire Specification |
11.00R20 / 12R22.5 tubeless tires (6-12 pieces, depending on axle configuration) |
|
Gross Mass |
Compliant with three-axle semi-trailer regulatory standards |
|
Brake System |
Pneumatic brake with ABS anti-lock system |
|
Frame Material |
High-strength Q345B or Q550 steel |
|
Fifth Wheel Kingpin Specification |
No. 50, No. 90 |
