Product Brief
It integrates "constant temperature control, enclosed protection, and stable transportation" in one, and is a dedicated cold-chain transport semi-trailer for cold-chain goods such as fresh produce and pharmaceuticals.
Product Details
The core of the compartment is a polyurethane foam insulation layer, which has strong heat insulation and lightweight properties. The inner and outer skins are made of FRP (Fiberglass Reinforced Plastic) sheets, balancing corrosion resistance and easy cleaning. The frame is constructed with high-strength steel to ensure load-bearing capacity, and components such as refrigeration unit brackets use galvanized parts to prevent rust.
The technical core focuses on cold-chain needs:
Precision Temperature Control System: Equipped with well-known brand compressor units and evaporators, it can achieve a wide temperature control range from -30℃ to 10℃, adapting to different cold-chain goods.
Sealing and Insulation Technology: Low-temperature resistant sealing strips are used at the compartment joints, and the door is equipped with an insulated locking structure, significantly reducing cold air loss.
Lightweight Optimization: Through material ratio adjustment, it reduces the overall vehicle weight while ensuring insulation performance, thereby lowering fuel consumption.
Product Parameters
|
Parameter |
Specifications |
|
Length (mm) |
13600, 13900, 15000, 16500 |
|
Width (mm) |
2500 |
|
Height (mm) |
4000 |
|
Rated Load Capacity |
30T, 35T, 40T, 50T |
|
Number of Axles (Optional) |
2-axle, 3-axle |
|
Compressor |
Equipped with Carrier Transicold 400 container units, U.S. Carrier 7300 units |
|
Body Material |
FRP (Fiberglass Reinforced Plastic) inside and outside the compartment; high-density insulation material |
Product Advantages
The core advantage of the refrigerated box-type semi-trailer lies in creating and maintaining an independent controllable low-temperature environment. Its high-performance insulated compartment is equipped with a refrigeration unit, which can accurately control the temperature within the range of -30℃ to +10℃, ensuring the quality and safety of frozen and refrigerated goods during long-distance transportation. The fully enclosed structure also has anti-theft, dustproof, and waterproof functions.
Applications
It is mainly used for transporting temperature-sensitive goods and is a backbone of cold-chain logistics. Typical scenarios include:
Transportation of frozen meat and aquatic products;
Fresh-keeping distribution of dairy products, fresh fruits, and vegetables;
Transportation of high-end temperature-controlled products such as pharmaceutical vaccines and biological agents;
Circulation of food ingredients in the food and beverage supply chain.
It serves as a "mobile cold storage" from the production area to the dining table, ensuring the required temperature is maintained throughout the entire process.
