Product Brief
The side-tip semi-trailer is a dedicated transport vehicle that uses a hydraulic lifting system to tilt the cargo compartment to one side, achieving fast and efficient self-unloading of materials.
Product Details
The core production material of the side-tip box-type semi-trailer is high-strength wear-resistant steel plates, which are used for the cargo compartment to withstand material impact and friction. The main beam is made of high-strength steel to ensure the overall rigidity during lifting.
Its technical core lies in the powerful hydraulic lifting system and the stable sub-frame structure design. Through high-power, multi-stage telescopic oil cylinders and a precise mechanical linkage mechanism, it realizes the stable and reliable lateral tilting of the cargo compartment to complete efficient self-unloading. At the same time, strict requirements are imposed on the vehicle's center of gravity and roll stability.
Product Parameters
|
Parameter |
Specifications |
|
Length (mm) |
11000, 12000, 13000, 14000 |
|
Width (mm) |
2500, 2550 |
|
Height (mm) |
2700, 2900, 3100, 3500 |
|
Style |
Single-side tip, Double-side tip |
|
Number of Axles (Optional) |
3-axle, 4-axle |
|
Oil Cylinders |
6+1 oil cylinders, 7+1 oil cylinders |
|
Body Material |
Full carbon steel |
Product Advantages
The core advantage of the side-tip semi-trailer lies in its ability to provide an integrated one-stop solution that efficiently combines "transportation" and "unloading".
Extreme Loading & Unloading Efficiency: Relying on a high-flow hydraulic lifting system, it can tilt the cargo compartment to one side stably and complete the self-unloading of dozens of tons of bulk materials within minutes. This completely eliminates reliance on on-site auxiliary equipment such as forklifts and loaders, significantly shortens the vehicle's stay time at loading and unloading points, and accelerates cargo turnover speed. It is especially suitable for short-distance transportation scenarios that require high-frequency and fast-paced loading and unloading.
Excellent Operational Economy & Reliability: The vehicle has undergone specialized reinforcement based on the characteristics of bulk material transportation. The cargo compartment is made of high-strength wear-resistant steel plates, which are impact-resistant and wear-resistant, ensuring a long service life.
Product Applications
The side-tip semi-trailer is a core piece of equipment in the construction and resource transportation sectors, and its application scenarios are highly focused on the rapid self-unloading of bulk materials.
It mainly undertakes the short-to-medium-distance transportation of bulk commodities such as sand, gravel, coal, ore, and grain. In construction projects, it can directly unload aggregates accurately into concrete mixing plants or construction site foundation pits. In mineral development and agricultural production, it provides efficient inbound and outbound solutions for coal, ore, corn, wheat, and other materials.
Its unique side-tip capability eliminates reliance on fixed unloading equipment, achieving seamless connection between "transportation and unloading". This greatly improves the turnover efficiency and operational flexibility of the logistics chain, making it a key tool for enhancing the efficiency of bulk material transportation.
